Accuton ceramic bass, C158-8-085

C158-8-085
286,75 € Без НДС
349.84 € с НДС для покупателей из ЕС

Accuton ceramic bass , C158-8-085

Количество
Товары, которые можно заказывать

CERAMIC BASS-MIDRANGE DRIVER

DOMEMATERIAL Ceramic
APPLICATION Bass‑Midrange
OVERALL DIAMETER 158 mm
CUTOUT DIAMETER/SQUARE 137 mm
OVERALL DEPTH 82 mm
MOTOR ASSEMBLY DEPTH 34 mm
MOTOR ASSEMBLY DIAMETER 85 mm

CLOSED BOX DESIGN PARAMETERS

Vb: 8.5L, -11dB @ 40Hz, F-3dB: 70Hz, Q: 0.71 (typical)

Vb: 22L, -8.5dB @ 40Hz, F-3dB: 70Hz, Q: 0.50 (extended bass)

VENTED BOX DESIGN PARAMETERS

Vb: 15L, Port diameter: 50mm, Length: 190mm, Fres: 41Hz, F-3dB: 45Hz, Q: 0.58 (typical)

Vb: 22L, Port diameter: 50mm, Length: 130mm, Fres: 40Hz, F-3dB: 40Hz, Q: 0.50 (extended bass)

Vb: 12L, Port diameter: 50mm, Length: 200mm, Fres: 45Hz, F-3dB: 49Hz, Q: 0.61 (0.7dB Ripple @ 100Hz)

SPECIFICATIONVALUEUNIT
OVERALL DIAMETER 158 mm
CUTOUT DIAMETER/SQUARE 137 mm
MIN. FRONTPLATE THICKNESS 6 mm
OVERALL DEPTH 82 mm
MOTOR ASSEMBLY DEPTH 34 mm
MOTOR ASSEMBLY DIAMETER 85 mm
SCREWFITTING DIN 7984, Ø 4,50 mm
TERMINAL + : 6.3 x 0.8 / - : 4.8 x 0.8 mm
SHIPPING WEIGHT (PAIR) 3.4 kg
SHIPPING BOX SIZE (PAIR) 200 / 200 / 250 mm

SPECIFICATIONVALUEUNIT
SENSITIVITY (2.83V / 1M) Lp 87,5 dB
DC-RESISTANCE Re 8.1 Ohm
RESONANCE FREQUENCY Fs 37 Hz
EQUIVALENT VOLUME OF AIR Vas 27.3 L
MECHANICAL Q Qms 4.91
ELECTRICAL Q Qes 0.39
TOTAL Q Qts 0.36
EFFECTIVE PISTON AREA Sd 113 cm²
MOVING MASS Mms 12.1 g
SUSPENSION COMPLIANCE Cms 1.5 mm/N
MECHANICAL RESISTANCE Rms 0.58 kg*s

SPECIFICATIONVALUEUNIT
POWER HANDLING P 100 Watt
LINEAR EXCURSION Xmax +/- 5 mm
VOICE COIL DIAMETER 25 mm
VOICE COIL FORMER MATERIAL Ti
VOICE COIL MATERIAL Cu
VOICE COIL INDUCTANCE Le 0.54 mH
FORCE FACTOR BI 7.7 N/A
MOTOR TYPE überhängig
FERROFLUID FILLING Nein

C158-8-085
