Accuton ceramic bass, C173-6-191-E

C173-6-191-E
241,15 € Без НДС
294.20 € с НДС для покупателей из ЕС

Accuton ceramic bass, C173-6-191-E

Количество
Товары, которые можно заказывать

Ceramic Bass-Midrange Driver

Domematerial Ceramic
Application Bass‑Midrange
Overall diameter 173 mm
Cutout Diameter/Square 146 mm
Overall depth 94.5 mm
Motor assembly depth 42 mm
Motor assembly diameter 120 mm

Vented box design parameters

Vb: 12L, Port diameter: 50mm, Length: 220mm, Fres: 45Hz, F-3dB: 50Hz, Q: 0.58 (optimal)

Vb: 18L, Port diameter: 50mm, Length: 150mm, Fres: 43.5Hz, F-3dB: 41Hz, Q: 0.50 (extended bass)

Vb: 10L, Port diameter: 50mm, Length: 240mm, Fres: 48Hz, F-3dB: 52Hz, Q: 0.61 (0.7dB Ripple @ 100Hz)

Closed Box design parameters

b: 6.5L, -13dB @ 40Hz, F-3dB: 76Hz, Q: 0.71 (typical)

Vb: 18L, -10dB @ 40Hz, F-3dB: 85Hz, Q: 0.50 (extended bass)

Mechanical Data
SpecificationValueUnit
Overall diameter 173 mm
Cutout Diameter/Square 146 mm
Min. frontplate thickness 6.35 mm
Overall depth 94.5 mm
Motor assembly depth 42 mm
Motor assembly diameter 120 mm
Screwfitting DIN 7984, Ø 4,50 mm
Terminal + : 6.3 x 0.8 / - : 4.8 x 0.8 mm
Shipping weight (pair) 5.3 kg
Shipping box size (pair) 210 / 280 / 210 mm
Thiele/Small parameters
SpecificationValueUnit
Sensitivity (2.83V / 1m) Lp 88 dB
DC-resistance Re 5.9 Ohm
Resonance frequency Fs 38.6 Hz
Equivalent volume of air Vas 21.6 L
Mechanical Q Qms 5.27
Electrical Q Qes 0.37
Total Q Qts 0.34
Effective piston area Sd 133 cm²
Moving mass Mms 19.8 g
Suspension compliance Cms 0.86 mm/N
Mechanical resistance Rms 0.91 kg*s
voice coil parameters
SpecificationValueUnit
Power handling P 120 Watt
Linear excursion Xmax +/- 5 mm
Voice coil diameter 38 mm
Voice coil former material Ti
Voice coil material Cu
Voice coil inductance Le 0.72 mH
Force factor BI 8.8 N/A
Motor type überhängig
Ferrofluid filling Nein
C173-6-191-E
